Recirculating Ball Screw
Recirculating ball screws convert rotary motion into precise linear motion through rolling balls, providing smooth movement, high rigidity, and reduced friction for demanding linear positioning systems. We support configurations for CNC equipment, machine tools, automated machinery, and space-constrained applications.
Technical Specifications
Custom Recirculating Ball Screw Configurations
All metal linear guide rail CNC systems can be configured around your machine requirements, technical drawings, existing components, and operating conditions.
Custom Screw Size & Lead
We can configure:
• Custom screw diameter and lead
• Custom overall screw length and thread length
• Application-matched stroke and travel requirements
• Custom shaft-end dimensions and machining
• Mounting dimensions matched to your equipment
Ball Nut Configuration
The ball nut can be configured according to:
• Nut type and mounting arrangement
• Flange dimensions and mounting holes
• Required preload and axial clearance
• Available installation space
• Existing machine interfaces
Recirculation Configuration
The ball screw can be configured with:
• Internal recirculation
• External recirculation
• End-cap recirculation
• Recirculation configuration matched to the nut design
• Compact configurations for space-constrained equipment
Precision & Performance
Selection can be matched to:
• Axial load
• Linear speed and maximum RPM
• Positioning accuracy
• Repeatability
• Required rigidity
• Backlash requirements
• Service life
• Mounting and support arrangement
Drawing / Existing Component
You can provide:
• CAD or technical drawings
• Ball screw and nut dimensions
• Shaft-end machining drawings
• Existing ball screw samples
• Machine interface dimensions
• Load, speed, stroke, and accuracy requirements
We can use these details to evaluate the required screw, nut, preload, recirculation configuration, and end machining.
Custom Manufacturing
We support custom:
• Screw dimensions
• Lead and length
• Ball nut configuration
• Flange and mounting dimensions
• Preload
• Recirculation configuration
• Shaft-end machining
• Application-specific requirements
Custom sizes can be evaluated according to your equipment requirements and production conditions. Samples can be produced for installation and performance approval before bulk production.
Get Custom Linear Guide Rail CNC Solutions
Applications of Recirculating Ball Screw
Recirculating ball screws support precise linear motion across compact equipment, machine tools, industrial systems, and automated machinery where smooth movement, rigidity, and reliable positioning are required.
- Space-Constrained Machinery
- General-Purpose Machine Tools
- Industrial Machinery
- Automated Machinery
- Other Related Equipment
Recirculating Ball Screw Manufacturing
JSM operates a 20,000 m² self-owned factory, 20+ production lines, CNC precision machining centers, and ultra-precision grinding equipment provide the manufacturing infrastructure for stable industrial supply.
Sample / Prototype Production
We support custom-size evaluation and sample production for installation and performance verification before volume orders, helping buyers validate fit and motion requirements before committing to production.
Batch Consistency
We operate under an ISO 9001 quality management system and conducts three-stage testing of raw materials and products to maintain accuracy and consistency across production batches.
Packaging
Automated packaging lines support standardized packing and efficient order fulfillment, helping protect precision linear motion components during handling and shipment.
Explore More About CNC Machines
Quality Control for Recirculating Ball Screw
Each recirculating ball screw is inspected across dimensions, accuracy, preload, recirculation, materials, machining, and application requirements to verify reliable motion performance and consistent quality.
Critical screw diameter, lead, overall length, nut dimensions, flange dimensions, mounting holes, and shaft-end features are inspected against approved drawings and specified tolerances.
Screw lead accuracy and linear travel are checked to verify consistent positioning performance across the required travel range.
Screw straightness and radial runout are inspected to control rotational stability and reduce vibration during high-speed operation.
Preload and axial clearance are checked according to the specified configuration to control backlash, rigidity, friction, and running smoothness.
Internal, external, or end-cap ball recirculation is inspected for correct assembly and smooth ball circulation throughout the nut.
Specified axial load, linear speed, RPM, stroke, duty cycle, and mounting conditions are reviewed to ensure the selected screw configuration matches the application.
Steel material and heat-treatment processes are controlled to support the required hardness, wear resistance, and service durability.
Precision-ground screw surfaces are inspected for machining quality and consistency required for smooth rolling contact.
Dust-proof features and protective components are checked to help maintain reliable operation in environments exposed to dust, debris, or foreign substances.
The completed ball screw assembly is checked for dimensions, running condition, appearance, and specified performance requirements before shipment.
B2B Support for Recirculating Ball Screw
JSM supports flexible sourcing with sample delivery, bulk-order planning, multiple trade terms, international shipping options, and a 1-year quality warranty.
MOQ: MOQ is confirmed according to the selected model, configuration, and order requirements.
Sample Delivery: Samples can be delivered within 14 days for installation and application testing.
Bulk Delivery: Bulk lead time is confirmed according to configuration, order quantity, and production requirements.
Trade Terms: FOB Shanghai, EXW, CIF, and DDP are available.
Shipping Methods: Sea freight, air freight, and express shipping are supported.
FAQ
Q: How does preload affect ball screw operation?
A: Proper preload reduces axial play and improves rigidity, while excessive preload can increase friction, heat generation, and drive torque.
Q: What causes axial play in a recirculating ball screw?
A: Axial play can result from insufficient preload, wear, improper installation, or clearance changes during operation.
Q: How should a ball screw be lubricated?
A: Lubrication should be selected and maintained according to operating speed, load, duty cycle, environment, and the manufacturer's recommended conditions.
Q: Can a recirculating ball screw work with linear guides?
A: Yes, ball screws are commonly paired with linear guides, with the ball screw providing linear transmission while the guide system supports and guides the moving load.
Q: What ball screw components need to be matched during replacement?
A: Replacement should match the screw, nut, mounting dimensions, lead, shaft-end machining, and installation interfaces of the existing system.
Q: How can ball screw noise and vibration be reduced?
A: Correct alignment, adequate lubrication, suitable preload, proper support, and controlled operating conditions help reduce noise and vibration.
Q: Can ball screw and bearing support be sourced together?
A: Yes, we provide ball screws and ball screw bearing supports as part of its linear motion component supply, which can simplify component matching and system procurement.
Custom Recirculating Ball Screw for Your Project
